SOEASY CAC solar panel ground carport mounting structure frame for car parking

SoEasy EAC-NW Solar Carport Mounting System is developed for different requirements of windload and snowload area, which is a more economical SoEasy carport solution. By optimizing the carport structure, it can achieve the clients requirments and reduce the cost. SoEasy will keep optimizing the design of solar carport mounting system to offer a excellent installation experience for users.

SoEasy CAC-NW Solar Carport Mounting System is developed for different requirements of windload and snowload area,

which is a more economical SoEasy carport solution.

By optimizing the carport structure, it can achieve the clients requirments and reduce the cost. SoEasy will keep optimizing the

design of solar carport mounting system to offer a excellent installation experience for users.





Installation Site
Open Ground
Foundation
Concrete Foundation
Panel Orientation
Landscape/Portrait
Applicable
Framed
Installation Angle
0 to 20 degree
Wind Speed
≥60m/s
Snow Load
1.7KN/m²
Design Standards
JIS c8955:2017;
AS/NZS 1170;
DIN1055;
ASCE/SEI 7-10;
International Building Code: IBC 2009
Ground Clearance
≥1800mm
Material
AL6005-T5
Fastener Material
SUS304
Component Material
SUS304 / AL6005-T5
Color
Sliver or Customized
Warranty
10 Years
 For more details, please contact us directly. 24 hours online



FEATURES
1、Customized solutions to maximize the utilization of land resources.
2、Simplifier structure design and easier to be installed.
3、Recyclable aluminum design row material.
4、10 years warranty, 25 years lifelong
5、Professional design solution and detailed manual will save the cost and time for installation
The solar carport mounting systems can stand up to the extreme weather condition. The main support components have also been tested to guarantee its structure and load-carrying capacity.
Our Service–Free Structure Design
Necessary info. for design and quote
1.What is your pv panels dimension? (L/W/H)
2.How many panel are you going to mount?
3.What is your planned panel layout?(row × column)
4.Max wind speed and snow load?

5.Tilt angle of bracket?
You can tell us what you need, such as tilt angle, planned panel layout.
