SOEASY Solar Ramming Pile Ground Mounting System

Name
Parameter
Application
Open terrain-ground mount
Wind load
≤ 42m/s
Snow load
1.4KN/m²
PV Modules
Framed, Unframed
Array Layout
According to the actual situation
Module Orientation
Landscape , Portrait
Module Inclination
0° – 25°
Ground Clearance
≥ 0.6m

Solar ramming pile solution is made of anodized aluminum and hdg q235b steel parts, which has increased the capable

of corrosion resistant. Ramming pile solution can use single or double pile as the project soil conditions. Highly

pre-assemble structure in factory and patent design can save the installation time and cost. Therefore, this solution is

widely used in large scale solar farm project.

Advantage

1. Fast installation & delivery

2. Easy, fast, and cost-effective installation

3. Height adjustment

4. Flexible orientation: landscape & portrait

Solar Racking System-3

Material AL 6005-T5/SUS304
Surface Treatment Average Anodizing Coating Thickness≥ 10μm Average
Panel Type Framed & Frameless
Wind Load ≤60m/s
Snow Load 1.4KN/m2
Panel Orientation Landscape/Portrait
Tilt Angle  0°~60°
Seismic Load Lateral Seismic Factor: Kp=1;  Seismic Coefficient: Z=1; Use Coefficient: I=1
Standards JIS C 8955 : 2017
AS/NZS 1170
DIN1055
ASCE/SEI 7-05
International Building Code: IBC 2009
 Warranty 10 Years Quality Warranty, 25 Years Life Span Warranty



Necessary info. for us to design and quote

1.What is your pv panels dimension?
_____mm Length x_____mm Width x____mm Thickness
2.How many panel are you going to mount?
_______Nos.
3.What is your planned panel layout?
________Nos. in a row × ________Nos. in a column
4.How is weather there, such as wind speed and snow load?
___m/s anit-wind speed and____KN/m2 snow load
5.May I know the tilt angle you need?
________degree
